Semi Automatic Stencil Printer Machine Programmable Motor Drive Print Heads
Features:
(1) The governor motor drive scraper, combining precision linear guide, ensure the printing precision;
(2) Printing scraper can rotate 45 degrees of fixed upwards, printing plate and scraper cleaning and replacement;
(3) The scraper holder can adjust forward and backward, to select the suitable printing position;
(4) Combined printing platen, has a fixed groove and positioning PIN, easy installation and adjustment, it is used for single and double panel printing;
(5) Steel bar-mesh mobile school edition way, combined with the printing machine (PCB) XYZ calibration adjustment, convenient and quick.
(6) Can be set unidirectional and bidirectional multiple printing methods.
Machine parameter:
| Model | ET-S1200 |
| PCB size | 1200×350 mm |
| Plate Area | 1250×320 mm |
| Stencil Frame Size | 470×370 mm～1300×550 mm (L×W) |
| Positioning way | positioning pin |
| Scraper Speed | 0-100 mm/sec |
| Power | 220V single phase, 50/60 HZ |
| Power Consumption | 120 W |
| PCB plate thickness | 0.2-2.0 mm |
| Plate Trimming | Front/back +/- 10mm Right/Left +/- 10mm |
| Printing Precision | +/- 0.05 mm |
| Air supply | 5-7 KGF/cm2 |
| Weight | 360 kg |
| Dimension | (L)1600 x(W)900 x(H)1650 mm |
Company profile:
Exhibition:
1.Domestic Exhibition: Guangzhou international lighting Exhibition; Shanghai Munich Exhibition; Chongqing LED Light Exhibition, etc.
2.Overseas Exhibition: India Delhi Exhibition, India Mumbai Exhibition, Pakistan Exhibition, Egypt Exhibition, Tunisia Exhibition, Thailand Exhibition, etc.
Packing:
Step one: Packing the machine with foam cotton stretch film.
Step two:Vacuum packaging, use strap to secure machine.
Step three:Professional wooden box packaging.
FAQ:
1.How can I buy this machine from you? ( Very easy and flexible !)
A. Consult us about this product on line or by e-mail.
B. Negotiate and confirm the final price , shipping , payment methods and other terms.
C. Send you the proforma invoice and confirm your order.
D. Make the payment according to the method put on proforma invoice.
2.How to ensure the quality of the machine?
We have our own industrial park. There are production centre and R&D centre and quality inspection centre to guarantee the machines quality. Before shipping, we will test the machine again to make sure the quality of the machine is good.
3.Are you a reliable partner?
Yes of course. We specialized in SMT pick and place machine over 10 years in Shenzhen China. Our products exported to over 20 countries and regions. We have been working with numerous big companies in India, Turkey, Pakistan,Egypt etc.
