SMT is surface mount technology (short for Surface Mount Technology) and is currently the most popular technology and process in the electronics assembly industry.
SMT includes surface mount technology, surface mount equipment, surface mount components, and SMT management. Features: high assembly density, small size and light weight of electronic products. The size and weight of patch components are only about 1/10 of that of traditional plug-in components. After SMT is generally used, the volume of electronic products is reduced by 40%~60%, and the weight is reduced by 60%. %~80%. High reliability and strong anti-vibration ability. The solder joint defect rate is low. High frequency characteristics are good. Reduced electromagnetic and radio frequency interference. Easy to automate and increase productivity. Reduce costs by 30% to 50%. Save materials, energy, equipment, manpower, time, etc.
A whole Automatic SMT line include Automatic printer, conveyor, pick and place machine and reflow oven
So what is the vaccum loader?
The suction machine uses vacuum suction to suck up the PCB and feed it into the solder paste printing machine to enter the next station, saving manual time
| Item | Vacuum loader |
| Dimension | L600*W950*H120mm |
| PCB size | L500*W390MM |
| PCB storage | 100PCS |
| Rail transfer height | 920±30mm |
| Shipping direction | Right to left/left to right |
| Conveyor belt | 7MM flat belt |
| Conveyor transmission speed | 9M/min |
| Operation control panel | Display control touch screen |
| Controller | Mitsubishi PLC programmable controller |
| Power supply | 2-phase 220V 50HZ |
| power | 0.1KW |
| Gas source | 0.4～0.6MPa |
| Weight | About 150KG |
| Electric control box | 1 Set |
Shenzhen Eton Automation Equipment Co., Ltd located in 44th, Building, 5th.Cuigang Industrial Area, Fuyong, Baoan District, Shenzhen, China. Eton company focus on building national brand and concentrate on providing customers professional guidance, good quality machines, good sale services of automatic SMT machines.
With the rapid development of the LED industry, ETON focuses on R&D and continuously enhances the competitiveness of its placement machines. Now we have successively reached strategic cooperation with many domestic and foreign companies. And has achieved everyone's unanimous recognition and praise. In the field of high-speed placement machines has become a leading Chinese brand.
If you have the requirement welcome to contact me.
